Righteous (Suzhou) Automation Co., Ltd., named after the last six letters of "INTELLIGENT" intelligent manufacturing, was founded in September 2018 with a registered capital of 10 million yuan. It is a non-standard integration supplier focusing on core manufacturing processes.

Righteous is committed to developing and manufacturing practical, reliable and efficient automatic assembly and performance testing equipment. At present, Rijie has made outstanding achievements in many fields, such as auto assembly and detection of auto parts, auto assembly and detection of electronic and electrical appliances, auto assembly and detection of household medical products, automatic control of image vision detection technology, and application of automatic unit of industrial robots.
More +
  • 300|+
      300+
      Qualification certificate
  • 200|+
      200+
      Number of employees
  • 1000|+
      1000+
      Strategic partners
  • 50000|m²
      50000
      Area covered

Large core diameter power cable processing lines

The wire body for our independent research and development, for the industry's first through the automated way to achieve 240 square large core diameter power cable 1, automatic wire feeding can achieve custom length that is the length of wire feeding can be edited at any time to adjust for the length of the harness needs, 2, fixed length cutting - can meet different cutting needs that cut the length and thickness of self-editing for different kinds of sets of terminals needs, 3, automatic set of terminals - through the mechanical design of effective Avoiding copper leakage and other defects, adjusting and replacing different tools for different types of terminals, 4. Automatic heat-shrinkable tube sleeving and marking - automatic cutting of heat-shrinkable tubes, cutting lengths to meet custom requirements, different channels to meet different types of sleeving, automatic winding and other processes. The line solves technical problems such as the exposure of copper to the sleeve terminals through technical means, and also solves the technical difficulty of unifying the first and last directions of winding. Data is collected for each process, recorded and uploaded to the host computer, and aggregated and displayed on a large screen for visual management, traceability and uniqueness of the product.
More +

Assembly line for electronically controlled shock absorbers with built-in solenoid valves

The assembly line is independently developed by our company, through the combination of man and machine to achieve precision and rapid assembly of products. 1, the whole line is automatically run, the manual is responsible for the loading and unloading of parts, the equipment completes the assembly of all parts and screening whether the product is qualified, while recording data; 2, the line body adopts quick change tooling, compatible with a variety of products; 3, all press fitting stations are servo press fitting, recording the pressure displacement curve at the same time 4. Each process is equipped with a double check function, which ensures that there will be no mis-assembly or omission through the combination of mechanical and electrical modes.

The whole line is controlled by PLC + field bus, and each station is equipped with a scanning gun, which effectively records the parameters of the product and transmits them to the upper computer, ensuring that all data in the assembly process of the line can be traced and has uniqueness.

More +

Wind turbine blade bolt sleeve prefabrication line

The assembly line is independently developed by our company and is the first line in the industry to realize the production of wind turbine blade sleeve products in an automated way, which adopts a flexible design and can realize the flexible production of all sleeve 1. The core difficulty of this line is to solve the automatic sandblasting and testing of the screw sleeve, glass fibre winding and knotting, automatic glue injection and other processes. And through the production line level quality tracking system to effectively monitor the parameters of the product process, the indicators parameters and products on the code, easy production management, later check.
More +

Intelligent production line for AC (DC) vehicle charging posts

The line is independently developed by our company, with a capacity of one set per minute. The line is equipped with automatic feeding of the charging pile shell, on-line detection of the main board, automatic feeding of the main board, mounting to the shell, automatic locking of the fixing screws and monitoring of the torque and displacement of the screws during locking. The line is equipped with automatic feeding and locking of the charging pile housing, automatic feeding of the motherboard, automatic feeding of the motherboard, mounting of the motherboard to the housing, automatic locking of the fixing screws and monitoring of the torque and displacement of the screws during locking. The finished charging pile performance testing, data collection and uploading monitoring, and the test results are recorded to the upper computer, the main board testing, performance testing for scanning records, to ensure that all data in the assembly process of the line can be tracked and unique The assembly line to use PLC + field bus control method to effectively monitor the parameters of the product, the indicators will be presented on the upper computer panel to achieve visualisation, to facilitate production management. Facilitates production management. The whole line requires only one person to make the rounds and replenish the materials, saving the amount of labour.
More +

Semiconductor raw materials

The assembly line is independently developed by our company, realizing the automatic assembly and testing of micro-torque products. 1, the whole line adopts the silo feeding method, only twice per shift, saving the cost of manual feeding; 2, the tightening axis with precision mechanical tooling, the whole tightening is less than 0.04N.m. 3, the product stop judgment and needle roller bearings use precision visual inspection, and the corresponding picture is bound with the product information code, to facilitate subsequent inspection. 4、The whole line adopts flexible mechanism to ensure accuracy and prevent damage to parts. All data is traceable and unique during the assembly process.
